| Frequency Range: | 136.00-174.00 MHz |
| 400.00- 520.00MHz | |
| Storage Channel | 128 |
| Step Frequency | 2.5/5/6.25/10/12.5/20/25KHz |
| Rated voltage | DC 7.4V |
| Frequency Stability | ±2.5ppm |
| Work Temperature | -20 ℃ to +60℃ |
| Battery Capacity | H-1800m Ah (Li-ion Battery) |
| Battery Life | About 12 Hours |
| Frequency Combination | PLL frequency synthesis |
| Antenna Impedance | 50 Ω |
| Work Mode | Same Frequency simplex Operation or Different Frequency simplex Operation |
| Dimension | 110x58x32 mm (Excluded Antenna) |
| Output Power | 5W/1W |
| Modulation Mode(W/N Band) | FM (F3E) |
| Maximum Frequency Deviation | ≤5 KHz |
| Spurious Power | ≤7.5 µW |
| Adjacent channel power | ≤-65dB/≤-60dB |
| Audio Distortion | <5 % |
| SNR | ≥-45dB/≥-40dB |
| CTSCC/DCS Frequency Deviation | 0.7±0.1KHz (W), 0.4±0.1KHz (N) |
| Modulation Sensitivity | 8-12mV |
| Transmitting Current | ≤1500mA |
| Sensitivity | ＜0.20 µ V (12dB SINAD) |
| Audio Power | 1 W |
| Inter modulation Interference Resistance | ≥65dB (W), ≥55dB (N) |
| Adjacent channel Sensitivity (W/N Band) | ≥65dB (W), ≥55dB (N) |
| Audio Distortion | 5 % |
| Receiving Current | ≤ 380m A |
